32" Ultra HD 4k resolution medical science monitor

32" widescreen with Ultra HD(High-Definition) 4K resolution
Resolution:3840(H) x 2160(V)
High Brightness and High Contrast Ratio
LED Backlight System
Multi-Picture display: Normal, PiP, PBP, 4P
14-bit LUT (Look Up Table) processing
DICOM Standard GSDF included (DICOM Part 14 Compliant)
DICOM Clear, Blue Mode support
Variable Gamma and DICOM (Color Temp) mode
Response Time (Typical):12ms (Gray to Gray)

32" Ultra HD 4k resolution medical science monitor

32" Ultra HD MEDICAL SCIENCE MONITOR
Display (type)	KSK-H320UHD
Response Time (Typical)	12ms (Gray to Gray)
Screen Size (Active Area)	31.5" (708.48(H) x 398.52(V) [mm])
Aspect Ratio	16:09
Number of Pixels	3840(H) x 2160(V)
Pixel Pitch (mm)	0.1845(H) mm x 0.1845(V) [mm]
Displayable Colors	1.07 billion (10-bit)
Brightness (Typical)	250 cd/m2
Display Mode	AHVA or AMVA
Contrast Ratio	1000:01:00
Viewing Angle (H/V°)	178/178
Touchscreen	No
power
Consumption	105.8W or 59.8W
Input	AC 100-240V, 50-60HZ, 6-3A
Signals
Output option	4K (HD, 3G, 6G) SDI (BNC) x1
Input	DisplayPort(1.2) x1, HDMI(1.4) x4, HDMI(2.0) x1, RGB x1, Audio x1
USB (up/down)	USB 2.0 x1/USB 2.0 x2
Output	DP(1.2) MST or Daisy chain x1, Audio x1
Environment
Temperature	Operating: 0° C ~ +40° C, Storage: -20° C ~ +60° C
Humidity	Operational: Ta = 40 °C , 85% RH; Storage MAX 85% RH, Ta = 40 °C
Altitude	Operational: 0 ~ 16,400 feet (5,000m); Storage/Shipment: 0 ~ 40,000 feet (12,192m)
IP Rating
Front	IP65
Top	IPX2
Physical Characteristics
Dimensions (W x D x H)	791.4(W) x 490(H) x 75(D) mm
Weight	11.2 kg
Features
Grayscale Performance	14-bit LUT (Look Up Table) processin
DICOM	Standard GSDF included (DICOM Part 14 Compliant), Clear, Blue Mode support
Certifications (option>100pcs)	CE MDD 93/42/EEC (EN60601-1:2006; EN60601-1-2:2007), RoHS II
Warranty	3 years

For the 32 inch medical monitor there are 4 different choices:
32 inch KSK-H320UHD(screen without touch function)
32 inch KSK-H320UHD-CAP(capacitive touch screen)
32 inch KSK-H320UHD-HL(screen without touch function but high brightness 700cd/m2)
32 inch KSK-H320UHD-HL-CAP(capacitive touch screen and high brightness 700cd/m2)
