55" IR touch all in one PC
- Type:All-In-One
- Screen Size:55"
- Processor Brand:Intel
- Memory Capacity:≥ 4GB
- Hard Drive Capacity:1TB
- Graphics Card Type:Integrated Card
- Display Type:LCD
- Widescreen:Yes
- Processor Main Frequency:2.4Ghz
- Brand Name:KIOSK
- Model Number:DL-AIO55
|
Specification |
|
|
Model No. |
DL-AIO55 |
|
Panel size |
55″ TFT-LCD |
|
Panel brand |
Sangsung or LG |
|
Input Frequency |
Horizontal:30-80KHZ,Vertical:60-75HZ |
|
Display area(mm)/mode |
16:9 |
|
Maximum resolution |
1920x1080P |
|
Display color |
16.7M |
|
Pixel Pitch(mm) |
0.264mmx0.264mm |
|
Brightness (nits) |
600cd/^2 |
|
Contrast |
1500:1 |
|
Visual angle |
65(L)/65(R)50(U)/50(D) |
|
CPU Master Frequency |
intel i3(2320 2.6GHz)/ i5 i7option |
|
chipset of MB |
intel H61 |
|
Memory |
4GB DDR3 |
|
Storage |
1TB HDD (barebone accept) |
|
Operating Sysem |
linux/ubuntu/win7/winXP |
|
graphics card video memory |
integrated Intel HD chipset |
|
Heat sink cooling |
80*2dual ball bearing |
|
touch screen input |
IR multi-touch screen |
|
Response time |
8ms |
|
Life(hrs) |
>50,000(hrs) |
|
Input and output |
|
|
RF |
1 |
|
HDMI INPUT |
2 |
|
S-VIDEO INPUT |
1 |
|
USB |
6 USB2.0 port(support 480Mb/s transfer rate) |
|
VGA |
1 |
|
AV INPUT |
2 |
|
YPbPr |
2 |
|
PC Audio INPUT |
1 |
|
Expansion slots |
PCI-E *1 |
|
SD/MMC/MS |
0 |
|
RG45(LAN) |
1 |
|
onboard SATA |
2 SATA port |
|
Video port |
HDMI + DVI/VGA |
|
onboard Audio |
6.1 channel Support MIC-in, Line–out, Line–in |
|
Wifi |
1 |
|
Speaker |
2×3W(4Ω) |
|
Video |
|
|
Color system |
PAL/SECAM |
|
Sound System |
BG/DK/I/L,L' ,NICAM/A2 |
|
Max. Channel Quantity |
99CH |
|
Remote controller |
IR Remote Controller |
|
OSD display( screen menu display) |
|
|
Menu language |
Chinese/English( Multiple Language Supported) |
|
Power |
|
|
Power supply |
AC100~240V 50 /60 HZ |
|
Maximum power consumption |
<=170W |
|
Standby power consumption |
<5W |
|
Temperature |
|
|
Working temperature |
0℃~50℃ |
|
Storage temperature |
-20℃~60℃ |
|
Working humidity |
85% |
|
Storage humidity |
85% |
|
Appearance |
|
|
Color/appearance |
White, black, customized |
|
Case |
Metal case SPCC |
|
Installation |
Stand/Wall mount |
|
Quality Standard |
ISO9001,CCC |
|
Detailed functions |
|
|
Built-in Analog Tuner |
ATSC |
|
Video format |
MPEG1/MPEG2/MPEG4/DivX/ASP/WMV/AVI |
|
Audio format |
Wave/MP3/WMA/AAC |
|
Image format |
JPEG/BMP/TIFF/PNG/GIF |
|
Image resolution |
480P/720P/1080P |
|
Optional Functions(Be free to contact sales man to confirm the Extra cost for optional) |
|
|
Digital TV System |
DVB-T/ISDB-T ATSC |
|
Bluetooth |
Y |
|
Tempered glass |
7 degree Glasses |
|
Outdoor Waterproof |
IP65/68 |
|
Light adjusting |
Levels according to the unit |
Packing
With years of export experience along with excellent quality, advanced services and competitive prices, Kiosk has won numerous customers' trust and support. About packing, we offer double or triple package or customized.
Delivery
1, Delivery time. we can only provide tracking number in 4~5 days after payment confirmed.
2,Import duties, taxes and charges are not included in the item price or shipping charges.These charges are the buyer's responsibility.Please check with your ountry's customs office to determine what these additional costs will be prior to placing;
