15.6 18.5 wall mount embedded touch IPC industrial medial grade computer
- screen:10.4 -24inch
- Resolution:1024*768 to 3840(H) x 2160(V)
- Response Time (Typical):3ms
- Interface:HDMI2.0/VGA/DP
- Aspect Ratio:16:9
- Brightness:350 cd/m2
- Touch screen: Capacitive touch screen option
|
wall mount embedded touch IPC industrial medial grade computer Specification |
|
|
Model No. |
Kk2APC |
|
Panel size |
2IN LED |
|
Panel brand |
innolux |
|
Input Frequency |
Horizontal:30-80KHZ,Vertical:60-75HZ |
|
Display area(mm)/mode |
16:9 |
|
Maximum resolution |
3840*2160 (4K) |
|
Support Colors |
16.7M |
|
Pixel Pitch(mm) |
0.2715(H) x 0.2715(V) |
|
Brightness (nits) |
1500cd/㎡ |
|
Contrast |
100:1 |
|
Visual angle |
CR>10 Horizontal/Vertical 178 Deg |
|
Response time |
type 3ms |
|
Life(hrs) |
LED Life Time>40,000(hrs) |
|
Input and output |
|
|
HDMI INPUT |
2 |
|
VGA |
1 |
|
DP INPUT |
1 |
|
USB 2.0 High Speed Port.OTG |
1 |
|
Speaker |
2*W(8Ω)* |
|
OSD display( screen menu display) |
|
|
Menu language |
Chinese/English( Multiple Language Supported) |
|
Power |
|
|
Power supply |
AC100~240V 50 /60 HZ |
|
power consumption |
Total18.35W@ cell 5.05W, BL13.3 (W) |
|
Temperature |
|
|
Working temperature |
0℃～50℃ |
|
Storage temperature |
－20℃~60℃ |
|
Appearance |
|
|
Color/appearance |
white/Silver/black by die |
|
Case |
plastic/Aluminum case |
1. Different Metal Case Optional.
2. No Frame Optional (SKD).
3. No Touch OR Resistive,Infrared,Capacitive Touch Optional.
4. HDMI 1.4*1; HDMI 2.1*1 DP1.0*1 .
6. Different Size 24-42inch Optional.
7. Desktop,Wall Mount Optional.
8. Customized Service.
Packaging & Shipping
Packing
With years of export experience along with excellent quality, advanced services and competitive prices, Kiosk has won numerous customers' trust and support. About packing, we offer double or triple package or customized.
Delivery
1, Delivery time. we can only provide tracking number in 3~7 days after payment confirmed.
2,Import duties, taxes and charges are not included in the item price or shipping charges.These charges are the buyer's responsibility.Please check with your country's customs office to determine what these additional costs will be prior to placing;
